— Computer —
G1 microServer
A compact, full-featured rugged server with removable high-capacity storage, optimized for SWaP-C constrained platforms.
40TB
Removable solid-state storage
2.4GHz
Octal-core Intel CPU
3.3 lbs
Minimum configuration weight
60,000 ft
Operating altitude
Description
The G1 microServer is a compact, full-featured server optimized for Size, Weight, Power and Cost (SWaP-C). Its design caters to space and power-constrained applications such as small unmanned aerial and ground systems. Equipped with four gigabit Ethernet ports and optional 10Gb Ethernet, it’s purpose-built for network attached storage applications. The high number of Ethernet ports often removes the need for external switches.
Advantage
Up to 40TB of removable storage with NIAP-approved dual-layer software and hardware full disk encryption, packaged in an ultra-small form factor with port density that often eliminates external switches.
Unmanned platforms
High-performance compute for UAVs and UGVs where size, weight and power budgets are tightly constrained.
Surveillance and ISR
Captures and stores high-bandwidth sensor data for surveillance, reconnaissance and intelligence missions in demanding environments.
Cockpit and flight systems
Supports flight management, map systems and cockpit information systems with secure encrypted storage at rest.
Key features & benefits:
Key features
- Intel C2758 octal-core CPU at 2.4GHz, 8GB ECC SDRAM
- Quad gigabit Ethernet plus optional 10GbE port
- Up to 40TB removable solid-state storage
- NIAP-approved dual-layer SWFDE and HWFDE
- 16V to 50V DC input, MIL-STD-810 / 461 / 704 qualified
Benefits
- Ultra-lightweight at 3.3 lbs minimum configuration
- SWaP-C optimized for constrained platforms
- High performance and high bandwidth in a small footprint
- Conduction-cooled and convection-cooled options
- Removable data module enables easy data transport
