— Computer —
AT50 Rugged Handheld Computer
5-inch ruggedized handheld computer with Intel Pentium N6415 processor, fanless design and military connectors for C5ISR mounted and dismounted operations.
5.0″
Integrated display
2.5 lbs
System weight
10W
Typical power consumption
40k ft
Operational altitude
Description
The AT50 is a ruggedized handheld computer integrating a 5.0″ TFT LCD display with an Intel Pentium N6415 quad-core processor, 4GB RAM and 64GB SSHD in a fanless aluminum enclosure at 2.5 lbs. Windows 10 or Linux, USB, RS-232 and Ethernet I/O and optional WiFi and GPS support deployed C5ISR applications. MIL-38999 or Glenair Mighty Mouse connectors and Helicoil mounts adapt the unit to handheld, dash-mount and bulkhead-mount installations.
Advantage
An Intel Pentium N6415 quad-core processor and 5-inch display in a 2.5-pound fanless enclosure deliver full Windows or Linux compute capability for the most demanding dismounted C5ISR missions.
Dismounted soldier systems
Provides a self-contained 2.5-pound computer and display for handheld C5ISR operations, with optional GPS and WiFi enabling standalone situational awareness without external infrastructure.
Combat and tactical vehicles
Dash-mount and bulkhead-mount configurations integrate the AT50 into vehicle crew stations as a self-contained mission computer and display for tactical data processing.
Fixed and rotary-wing aircraft
Mounts in cockpit and mission crew stations delivering fanless compute and display at 40,000 ft operating altitude with optional high-bright display for all lighting conditions.
Key features & benefits:
Key features
- Intel Pentium N6415 quad-core processor, 4GB RAM and 64GB SSHD in a fanless enclosure
- Integrated 5.0″ TFT LCD with 300-nit standard and 800-nit high-bright option
- Windows 10 or Linux OS with USB, RS-232 and Ethernet I/O
- MIL-38999, D-Sub or Glenair Mighty Mouse connector options
- Optional WiFi 802.11 and commercial GPS with sealed SMA connector
Benefits
- Complete computer and display at 2.5 lbs eliminates separate display and compute hardware
- 10W fanless operation extends battery endurance in dismounted soldier configurations
- Fully enclosed aluminum resists salt fog, sand, moisture and fungus
- Day/Night controls and high-bright option maintain display visibility in all ambient conditions
- Configurable I/O and Helicoil mounts adapt the unit to handheld, dash and bulkhead installations
